使用用途与介绍/Brief Introduction：

机器组为10-20ml内服液气体罐装制作线中的主要的设施机械设备。是由洗瓶、烘烤一身机和罐装密封处一身机所组建，能自动式顺利完成内服液瓶的洗瓶、烘烤、罐装和密封处等拉伸动作，是内服液制作制造商更佳的整套搭配设施机械设备，几乎合适GMP想要。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

优势/Characteristic：

◆装量明确，拒绝漏滴。罐装高精度更高。High filling accuracy.◆调频魔宗变速，出产车速可手动调节，自选择有差异 的出产车速。Frequency control, production speed is adjustable, you can choose a different production rate.◆一切设备组件均适用进出口有名的该品牌。All electrical components are imported famous brands.◆自主现示运算职能。Automatically countting function.◆掌控用于德国三凌PLC，抗干涉，任务安全。Controlled by Mitsubishi PLC◆机械性能稳固，维持皮肤保养以便于。Stable performance, easy maintenance.◆裸机的外表选用SUS304不锈碳钢作、与原辅料接触性位置选用316L不锈钢材质的管。裸机完全性按GMP的要求的设计。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

系统技术指标/technical parameters：

不适用产品规格/Bottle size	10-20ml
产出业务能力/Capacity	60-90瓶/7分钟/60-90bottles/min
干燥气温/Dryer tempreture	100-300°
回收河水量/Water wastage	0.5m3/h
自净水耗量/Purifying water consumption	0.3m3/h
装量误差/Filling precision	≤1%
供电/Voltage	380V/50Hz
功效/Power	33KW
出产线总长/Dimension	3500×1500×1600mm
